Standard equipment:

  • Straight telescopic boom with moment controll system
  • 230V AC power source
  • Wheel assist
  • Autoplatform leveling with auto correction at 3°
  • Chassis level sensor 1,5°
  • Alu basket with wide tool tray, safety handrail and dual harness points
  • Proportional electro-hydraulic controls by fingertip joysticks
  • Ground pressure sensors on all outrigger plates with audible and visible alarms
  • 230V outlet in the basket
  • Hourmeter
  • CE cert and EU road typ approvel
  • Ground and upper controls with tarp cover
  • Manual recovery with hand pump
  • Automatic reverse and overrun brakes
  • Colour of the machine: RAL3002 (red)

Optional:

  • Auto classic level
  • Dual power source 230V & Honda
  • Battery power 24V 225 Ah
  • Custom colour
  • G.R.P. basket with tool tray (2 person)
  • Outrigger plate pads
Working Height  13 m
Platform Height  11 m
Horizontal Reach (220kg)  7 m
Horizontal Reach (100kg)  9 m
Platform Capacity  220 kg
Slewing  365°
Platform dimensions  1,4x0,7x1,1 m
Platform rotator  2x45°
Transport length  5,95 m
Transport width  1,58 m
Transport height  1,99 m
Total weight: (230V, wheel assist)  ca. 1460 kg
Total weight (230V, Honda, wheel assist)  ca. 1495 kg
Total weight (battery 24VDC, wheel assist)  ca. 1580 kg
Outrigger footprint Outrigger plate outer edge  ca. 3,72 m
Gradeability  6,8° (12%)
Max. towing speed  80 km/h
Brake  Overrun Brakes with Gas Spring
Tyres  195 R 14 C
